The 500 series is one of the best performing subs you can find in its power class. With a highly efficient design, the 500 series can easily be driven to high output levels on as little as 150-400 Watts. When compared to the 200 Series the 500 Series uses a longer coil, more powerful motor and the suspension is designed to handle higher transient peaks. These are very versatile subs that work well in sealed enclosures while providing the extra energy and control needed for vented enclosures applications.
500 Series Features:
EROM surround
High-temp, 2.0”, voice coil
Double Layer Deep bass, high excursion spider system
Unique glass fiber and natural pulp cone
Backplate coil gap venting
Extended pole piece
DD stamped steel basket
MODEL 512D
Driver Size 12"
Watts RMS 150 - 400
Peak Power 1200
VCD 2
Impedance D2 / D4
Piston Dia - in 10 3/16
Fs - Hz 25.57
Qms 4.614
Qes 0.4701
Qts 0.4266
Vas - liters 86.42
Xmech - mm 64
Xmax - mm 11
Frame OD - in 12 1/4
Frame OD w/Gasket - in 12 1/2
Mounting Diameter - in 11 1/16
Mounting Depth - in 5 7/8
Motor Diameter - in 5 1/2
Motor Depth - in 2
Woofer Displacement - cu ft 0.09
Sealed Enclosure - cu ft 0.5 - 1.0
Ported Enclosure - cu ft 1.75 - 2.75
Shipping Weight - lbs 15
--
The 500 series is one of the best performing subs you can find in its power class. With a highly efficient design, the 500 series can easily be driven to high output levels on as little as 150-400 Watts. When compared to the 200 Series the 500 Series uses a longer coil, more powerful motor and the suspension is designed to handle higher transient peaks. These are very versatile subs that work well in sealed enclosures while providing the extra energy and control needed for vented enclosures applications.
500 Series Features:
EROM surround
High-temp, 2.0”, voice coil
Double Layer Deep bass, high excursion spider system
Unique glass fiber and natural pulp cone
Backplate coil gap venting
Extended pole piece
DD stamped steel basket
MODEL 512D
Driver Size 12"
Watts RMS 150 - 400
Peak Power 1200
VCD 2
Impedance D2 / D4
Piston Dia - in 10 3/16
Fs - Hz 25.57
Qms 4.614
Qes 0.4701
Qts 0.4266
Vas - liters 86.42
Xmech - mm 64
Xmax - mm 11
Frame OD - in 12 1/4
Frame OD w/Gasket - in 12 1/2
Mounting Diameter - in 11 1/16
Mounting Depth - in 5 7/8
Motor Diameter - in 5 1/2
Motor Depth - in 2
Woofer Displacement - cu ft 0.09
Sealed Enclosure - cu ft 0.5 - 1.0
Ported Enclosure - cu ft 1.75 - 2.75
Shipping Weight - lbs 15
