The 500 series is one of the best performing subs you can find in its power class. With a highly efficient design, the 500 series can easily be driven to high output levels on as little as 150-400 Watts. When compared to the 200 Series the 500 Series uses a longer coil, more powerful motor and the suspension is designed to handle higher transient peaks. These are very versatile subs that work well in sealed enclosures while providing the extra energy and control needed for vented enclosures applications.
500 Series Features:
- EROM surround
- High-temp, 2.0”, voice coil
- Double Layer Deep bass, high excursion spider system
- Unique glass fiber and natural pulp cone
- Backplate coil gap venting
- Extended pole piece
- DD stamped steel basket
| MODEL | 510D |
| Driver Size | 10" |
| Watts RMS | 150 - 400 |
| Peak Power | 1200 |
| VCD | 2 |
| Impedance | D2 / D4 |
| Piston Dia - in | 8 1/8 |
| Fs - Hz | 30.28 |
| Qms | 4.321 |
| Qes | 0.4602 |
| Qts | 0.4159 |
| Vas - liters | 27.44 |
| Xmech - mm | 64 |
| Xmax - mm | 10 |
| Frame OD - in | 10 1/8 |
| Frame OD w/Gasket - in | 10 3/8 |
| Mounting Diameter - in | 9 3/16 |
| Mounting Depth - in | 5 1/4 |
| Motor Diameter - in | 5 1/2 |
| Motor Depth - in | 2 |
| Woofer Displacement - cu ft | 0.07 |
| Sealed Enclosure - cu ft | 0.4 - 0.8 |
| Ported Enclosure - cu ft | 1.25 - 1.5 |
| Shipping Weight - lbs | 15 |
